Djikstra algorithm

Djikstra’s algorithm which was conceived by computer scientist Esdger W. Djikstra in 1956 is an algorithm for finding the shortest paths between nodes in a graph, which may represent for example, road networks. The algorithm exists in many variants. The original algorithm from 1956 was initially searching for the shortest path between two given nodes. However, in practice a more common variant consist in fixing a single node as the "source" node and then find the shortest paths from the source to all other nodes in the graph through the production a shortest-path tree.

Djikstra formula

The Dijkstra algorithm uses labels that are positive integers or real numbers, which are totally ordered. It can be generalized to use any labels that are partially ordered, provided the subsequent labels (a subsequent label is produced when traversing an edge) are monotonically non-decreasing.

This generalization is called the generic Dijkstra shortest-path algorithm. Dijkstra's algorithm uses a data structure for storing and querying partial solutions sorted by distance from the start. While the original algorithm uses a min-priority queue and runs in time :

With :
| V | : the number of nodes
| E | : the number of edges

The idea of this algorithm is also given in Leyzorek et al. 1957. Fredman & Tarjan 1984 propose using a Fibonacci heap min-priority queue to optimize the running time complexity to :

With :

| E | : the number of edges

This is asymptotically the fastest known single-source shortest-path algorithm for arbitrary directed graphs with unbounded non-negative weights. However, specialized cases (such as bounded/integer weights, directed acyclic graphs etc.) can indeed be improved further as detailed in Specialized variants.

Notes :
In some fields, artificial intelligence in particular, Dijkstra's algorithm or a variant of it is known as uniform cost search and formulated as an instance of the more general idea of best-first search.

Algorithm definition :

The enunciate of the Dijkstra's algorithm is the following :

Let the node at which we are starting be called the initial node.
Let the distance of node Y be the distance from the initial node to Y.
Dijkstra's algorithm will assign some initial distance values and will try to improve them step by step as follows :

1) Mark all nodes unvisited. Create a set of all the unvisited nodes called the unvisited set.

2) Assign to every node a tentative distance value: set it to zero for our initial node and to infinity for all other nodes. Set the initial node as current.

3) For the current node, consider all of its unvisited neighbours and calculate their tentative distances through the current node. Compare the newly calculated tentative distance to the current assigned value and assign the smaller one. For example, if the current node A is marked with a distance of 6, and the edge connecting it with a neighbour B has length 2, then the distance to B through A will be 6 + 2 = 8. If B was previously marked with a distance greater than 8 then change it to 8. Otherwise, the current value will be kept.

4) When we are done considering all of the unvisited neighbours of the current node, mark the current node as visited and remove it from the unvisited set. A visited node will never be checked again.

5) If the destination node has been marked visited (when planning a route between two specific nodes) or if the smallest tentative distance among the nodes in the unvisited set is infinity (when planning a complete traversal; occurs when there is no connection between the initial node and remaining unvisited nodes), then stop. The algorithm has finished.
Otherwise, select the unvisited node that is marked with the smallest tentative distance, set it as the new "current node", and go back to step 3.

Observation

When planning a route, it is actually not necessary to wait until the destination node is "visited" as above: the algorithm can stop once the destination node has the smallest tentative distance among all "unvisited" nodes (and thus could be selected as the next "current").

Illustration of Dijkstra's algorithm use

If the nodes of the graph represent cities and edge path costs represent driving distances between pairs of cities connected by a direct road (for simplicity, ignore red lights, stop signs, toll roads and other obstructions), Dijkstra's algorithm can be used to find the shortest route between one city and all other cities.
A widely used application of shortest path algorithm is network routing protocols, most notably IS-IS (Intermediate System to Intermediate System) and Open Shortest Path First (OSPF). It is also employed as a subroutine in other algorithms such as Johnson's.
